Trend 342X1/4TC 1/4" Shank TCT Biscuit Jointer Router Cutter Set

Summary

The Trend 342X1/4TC is a professional TCT biscuit jointer set designed for use with a router to cut accurate biscuit slots in timber, man-made boards and particle board. The set includes three interchangeable bearings that set the precise groove depth for each of the three standard biscuit sizes, eliminating the need for manual depth adjustment. Suitable for cabinet making, furniture assembly and general joinery where strong, aligned butt joints are required.

Features

• Cuts biscuit slots in timber, MDF, man-made fibre and particle board using a standard router
• Three bearing sizes included - each sets the correct groove depth automatically for the corresponding biscuit size
• Slightly longer slot cut than biscuit length allows lateral play for easy alignment during assembly
• PVA water-based glue is used with biscuits; moisture causes biscuits to expand for a tight, secure joint
• Boards are clamped together until the glue cures - no specialist equipment required
• Biscuits can be doubled up with two passes for extra strength on larger boards
• Tungsten carbide tipped (TCT) cutting edges for durability and clean slot walls
• 1/4" shank for compatibility with standard router collets

Specifications

• SKU: 342X1/4TC
• Shank Diameter: 1/4 inch
• Cutter Diameter (D): 40 mm
• Overall Length (OL): 63.5 mm
• Cutting Height (C): 4 mm
• Bearing 1 (B): 15 mm - Biscuit No. 0, Groove Depth 8.5 mm
• Bearing 2 (B2): 19 mm - Biscuit No. 10, Groove Depth 10.5 mm
• Bearing 3 (B3): 23 mm - Biscuit No. 20, Groove Depth 12.5 mm
• For Biscuit Sizes: No. 0, No. 10 and No. 20
• Groove Depths: 8.5 mm, 10.5 mm and 12.5 mm

What's Included

• 1 x TCT biscuit jointer cutter (1/4" shank)
• 3 x bearings (15 mm, 19 mm and 23 mm) for biscuit sizes No. 0, 10 and 20
