JCP Fixings Countersunk Concrete Screw with Cover Cap and T30 Bit ZYP 7.5 x 100mm (Bag of 55)

Summary

The JCP Fixings countersunk concrete screw is a self-tapping masonry fixing designed for direct installation into concrete, concrete blocks, brick, and other masonry substrates without the need for a wall plug. Supplied in a bag of 55 with a white cover cap for a neat finished appearance and a T30 driver bit included for immediate use. The zinc and yellow passivated finish provides reliable corrosion resistance for both internal and external applications.

Features

• Self-tapping countersunk head design allows direct fixing into masonry without an expansion anchor or plug.
• Suitable for use in concrete, concrete blocks, solid brick, perforated brick, and natural stone substrates.
• Serrated V-thread profile achieves optimum engagement across all masonry types and provides high pull-out resistance.
• High-low thread form on the leading section aids insertion and reduces installation torque.
• T30 Torx drive recess minimises driver wear and prevents cam-out during installation.
• Flat countersunk head with locking ribs sits flush for a clean, professional finish.
• Zinc and yellow passivated (ZYP) finish delivers increased resistance to corrosion.
• White cover cap included to conceal the screw head for a tidy finished look.
• Ideal for fitting window frames, door frames, timber battens, metal profiles, and panels into masonry.

Specifications

• Size: 7.5 x 100mm
• Head Type: Flat countersunk
• Drive: T30 Torx
• Finish: Zinc and Yellow Passivated (ZYP)
• Recommended Drill Bit Size: 6.0-6.5mm
• Pack Quantity: 55
• Article Number: JP3033
• Product Code: FJPOCS75100

What's Included

• 55 x JCP 7.5 x 100mm countersunk concrete screws (ZYP)
• White cover caps
• T30 Torx driver bit
