ITWCP Spit Hit-M CSK M6 x 52mm Hammer Fixing

Summary

The ITWCP Spit Hit-M CSK is a nylon countersunk hammer-in anchor designed for fast, reliable fixing into masonry, concrete, and brickwork. Carrying ETA Approval, it is the benchmark hammer-in anchor for electrical installation and drywall applications. Its pre-expansion design allows the fixing to be driven home cleanly without premature sleeve expansion.

Features

• Hammer-in installation: the drive nail is hammered against the pre-expansion collar, fully locating the sleeve before expansion begins.
• Secure expansion: further hammering or screw tightening causes the sleeve to expand and lock firmly within the substrate.
• Countersunk head sits flush with the fixture surface once fully driven.
• Polyamide 6 sleeve resists weathering, ageing, and rotting, and offers good electrical insulation.
• Sleeve rated for temperatures from -20 degC to +60 degC, suitable for demanding site conditions.
• High tensile and compressive strength with broad resistance to chemical attack.
• Zinc-plated steel screw (5 um) provides corrosion protection; A4 stainless steel screw option available.
• ETA Approved for use in concrete and masonry applications.

Specifications

• Brand: ITWCP / Spit
• Product Range: Hit-M CSK
• Thread Diameter: M6
• Length: 52 mm
• Sleeve Material: Polyamide 6 (nylon)
• Screw Finish: Zinc plated 5 um
• Head Type: Countersunk (CSK)
• Temperature Range: -20 degC to +60 degC
• Part Number: 050131

What's Included

• M6 x 52mm Spit Hit-M CSK hammer fixings (quantity as per pack selected)
